This mixing valve delivers safe, blended hot water to taps, showers and other water outlets, making it ideal for use in hospitals, care establishments, schools and leisure centres. Has been independently tested and approved by the TMV3 scheme as a type 3 valve under the requirements of the National Health Service – Model Engineering Specification – DO8.
BLENDING VALVESÂ TMV3 Mixing Valve
- Automatic shutoff in the event of hot or cold water supply failure
- Check valves and serviceable filters as standard
- Operates at a maximum pressure differential of 10:1
- High pressure bath fill Part G compliant
Approved By WRAS, TMV2 & TMV3
Certification N.H.S. Requirement D08
Inlet Temperature Max. hot: 85°C
Pressure 10 bar
Pressure Range low 0.2 to 1 bar, high 1 to 5 bar
Size 15 mm
Temperature Range 30 to 46°C
